    TP316L Bright Annealed stainless steel seamless pipe SCH160 thickness

    Ask Lasest Price
    Brand Name : HDT
    Model Number : TP316L
    Certification : ISO 9001, ASME, TUV, EN
    Price : 7,000 - 10,000 USD per ton
    Payment Terms : L/C, T/T
    Supply Ability : About 3,000 tons per onth
    Delivery Time : 90 days after getting the down payment or L/C
    • Product Details
    • Company Profile

    TP316L Bright Annealed stainless steel seamless pipe SCH160 thickness

    TP316L Bright Annealed Seamless Stainless Tube Corrosion Resistant 76x6x6000mm


    ItemDescription
    Basic InformationMaterial GradeTP304 , TP304L , TP304H , TP316 , TP316L , TP316Ti , TP309S , TP310S , TP321 , TP321H , TP347 , TP347H , S31803 , S32750 , S32205 etc
    Outer Diameter6.00mm - 48.00mm
    Wall Thickness0.71mm - 2.11mm
    LengthNormally fixed length 6m , can as per customer’s requirement
    StandardASTM A213 ; ASTM A269 ; ASTM A312 ; ASTM A789 ; ASTM A790 ect .
    Process MethodCold Drawn or Cold Rolled

    ASME SA213 / A213 : Standard Specification for Seamless Ferritic and Austenitic Alloy-Steel Boiler , Superheater and Stainless Steel Heat Exchanger Tubes .

    ASTM A249 / A249M : Standard Specification for Welded Austenitic Steel Boiler , Superheater Heat-Exchanger , and Condenser Tubes .


    Application :


    1 . For fluid & gas transport

    2 . Petrochemical

    3 . Environmental protection

    4 . Structure & Machining

    5 . Electricity

    6 . Instrument industry etc


    Stanard Wire Gauge ( Fomerly Imperial Wire Gauge ) SWG
    SWGWall ThicknessSWGWall Thickness
    00.3248.23210.0320.81
    10.37.62220.0280.71
    20.2767.01230.0240.61
    30.2526.4240.0220.56
    40.2325.89250.020.51
    50.2125.38260.0180.46
    60.1924.88270.01640.42
    70.1764.47280.01480.38
    80.164.06290.01360.35
    90.1443.66300.01240.31
    100.1283.25310.01160.29
    110.1162.95320.01080.27
    120.1042.64330.010.25
    130.0922.34340.00920.23
    140.082.03350.00840.21
    150.0721.83360.00760.19
    160.0641.63370.00680.17
    170.0561.42380.0060.15
    180.0481.22390.00520.13
    190.041.02400.00480.12
    200.0360.91

    EN10216-5 Standard Chemical Composition :


    Steel GradeCSiMnPSNCrCuMoNbNiTiOthers
    max  maxmax
    Steel NameSteel Number
    X2CrNi19-111.43060.03≤1≤20.040.015≤0.1118.00 - 20.00---8.00 - 10.00--
    X5CrNi18-101.43010.07≤1≤20.040.015≤0.1117.00 - 19.50---8.00 - 10.50--
    X6CrNiTi18-101.45410.08≤1≤20.040.015≤0.1117.00 - 19.00---9.00 - 12.005xC to 0.70-
    X6CrNiNb18-101.45500.08≤1≤20.040.015-17.00 - 19.00--10xC to 1.009.00 - 12.00--
    X2CrNiMo17-12-21.44040.03≤1≤20.040.015≤0.1116.50 - 18.50-2.00 - 2.50-10.00 - 13.00--
    X5CrNiMo17-12-21.44010.07≤1≤20.040.015≤0.1116.50 - 18.50-2.00 - 2.50-10.00 - 13.00--
    X6CrNiMoTi17-12-21.45710.08≤1≤20.040.015-16.50 - 18.50-2.00 - 2.50-10.50 - 13.505xC to 0.70-

    ASTM A213 / A213M Standard Chemical Composition :


    Elements304L(wt%) S30403304(wt%) S30400316L (wt%) S31603316 (wt%) S31600
    (C) Carbon, max0.0350.080.0350.08
    (Mn) Manganese, max2222
    (P) Phosphorus, max0.0450.0450.0450.045
    (S) Sulfur, max0.030.030.030.03
    (Si) Silicon, max1111
    (Ni) Nickel8.0 - 12.08.0 - 11.010.0 - 14.010.0 - 14.0
    (Cr) Chromium18.0 - 20.018.0 - 20.016.0 - 18.016.0 - 18.0
    (Mo) MolybdenumN/AN/A2.0 - 3.02.0 - 3.0
    (Fe) IronBal.Bal.Bal.Bal.
    (Cu) CopperN/AN/AN/AN/A
    (N) NitrogenN/AN/AN/AN/A

    ASTM A312 / A312M Standard Chemical Composition :


    Elements304L(wt%)316L (wt%)
    (C) Carbon, max0.0350.035
    (Mn) Manganese, max22
    (P) Phosphorus, max0.0450.045
    (S) Sulfur, max0.030.03
    (Si) Silicon, max11
    (Ni) Nickel8.0 - 13.010.0 - 14.0
    (Cr) Chromium18.0 - 20.016.0 - 18.0
    (Mo) MolybdenumN/A2.0 - 3.0
    (Fe) IronBal.Bal.
    (Cu) CopperN/AN/A
    (N) NitrogenN/AN/A
