    Stainless Steel Bright Annealed Welded Pipes Round ASTM A358 Standard

    Ask Lasest Price
    Brand Name : HDT
    Model Number : TP304,TP304L,TP304H,TP321,TP316L,S31803,SUS304,SUS304L,SUH304H,SUS321,SUS316L,SUS329J3L
    Certification : ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
    Price : 800 - 9000 USD / ton
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : About 10000 ton / month
    Delivery Time : 60-75days
    • Product Details
    • Company Profile

    Stainless Steel Bright Annealed Welded Pipes Round ASTM A358 Standard

    Bright Annealed Stainless Steel Welded Pipes High Precision ASTM A358 Standard


    Hua Dong Energy Technology has more than 35 years experience for heat exchanger tube / boiler tube/ cooling tube,



    Stainless Steel Welded Pipes ASTM A358 TP304 TP304L TP304H TP321 TP316L ASTM A790 S31803, SCH10, SCH40,6M 11.8M


    YUHONG SPECIAL STEEL deal with stainless steel welded pipe and tube already more than 10 years, every year sell more than 5000 tons of stainless steel pipe and tube. Our client already cover more than 45
    countries. Our stainless steel seamless pipe and tube was width used in Mining, Energy, Petrochemical,
    Chemical Industry, Food plant, Paper plant, Gas and Fluid Industry etc.
    Standard Specification:
    ASTM A249 / A249M - 10a Standard Specification for Welded Austenitic Steel Boiler, Superheater,
    Heat-Exchanger, and Condenser Tubes
    ASTM A269 - 10:Standard Specification for Seamless and Welded Austenitic Stainless Steel Tubing
    for General Service
    ASTM A312 / A312M - 12:Standard Specification for Seamless, Welded, and Heavily Cold Worked
    Austenitic Stainless Steel Pipes
    ASTM A358/A358M-08a:Standard Specification for Electric-Fusion-Welded Austenitic
    ASTM A778 - 01(2009)e1:Standard Specification for Welded, Unannealed Austenitic Stainless
    Steel Tubular Products
    ASTM A789 / A789M - 10a:Standard Specification for Seamless and Welded Ferritic Austenitic Stainless Steel Tubing for General Service
    ASTM A790 / A790M - 11:Standard Specification for Seamless and Welded Ferritic Austenitic Stainless Steel Pipe
    Others like BS, JIS , DIN , EN , GOST standard we all can supply .
    Material Grade:

    American StandardAustenitic Steel:
    TP304,TP304L,TP304H, TP304N, TP310S,TP316,TP316L,TP316Ti,TP316H, TP317,TP317L, TP321, TP321H,TP347, TP347H,904L…
    Duplex Steel :
    S32101,S32205,S31803,S32304,S32750, S32760
    Others:TP405,TP409, TP410, TP430, TP439,...
    Europen Standard1.4301,1.4307,1.4948,1.4541,1.4878,1.4550,1.4401,1.4404,1.4571,1.4438, 1.4841,1.4845,1.4539,1.4162, 1.4462, 1.4362, 1.4410, 1.4501
    Russia Standard08Х17Т,08Х13,12Х13,12Х17,15Х25Т,04Х18Н10,08Х20Н14С2, 08Х18Н12Б,10Х17Н13М2Т,10Х23Н18,08Х18Н10,08Х18Н10Т, 08Х18Н12Т,08Х17Н15М3Т,12Х18Н10Т,12Х18Н12Т,12Х18Н9, 17Х18Н9, 08Х22Н6Т, 06ХН28МДТ



    Designation: A358/A358M-08a / ASTM A790 / A790M - 11:
    Standard specifications For Welded,And Heavily Cold Worked Austenitic
    Stainless Steel Pipe
    If client has inspection requirements, we can accept the following inspection:

    Manufacture ProcessERW Welded ( ELD ) Pipe



    Quality Inspection

    1. Metallographic Analysis
    2. Physical And Chemical Analysis
    3. Specification Eccentricity Test
    4. Mechanical Test
    5. PMI Test
    6. Eddy Current Test
    7. Large-Size Ultrasonic Flaw Test
    8. Ultrasonic Flat Test
    9. Thickness Test etc.



    Mechanical Requirements
    Grade UNS Designation Tensile Strength Yield Strength
    Min Ks i [M pa] Min Ks i [M pa]
    TP304 S30400 75 [515] 30 [205]
    TP304L S30403 70 [485] 25 [170]
    TP309S S30908 75 [515] 30 [205]
    TP310S S31008 75 [515] 30 [205]
    TP316L S31603 70 [485] 25 [170]
    .... .... ..... ....

    1. Specification
    2. Grade
    3. OD
    4. Wall
    5. SMLES OR WELDED ...
    • ASTM A358, ASTM A790
    • TP304,TP304L,TP304H,TP321,TP316L,S31803....
    • 6.00MM-830MM
    • 0.5MM-48MM
    • WELDED .....


    Size Range:

    ProductionOutside DiameterWall Thickness
    Welded Pipe6.00mm to 830mm0.5mm to 48mm



    Final Finishing:
    Solution Annealed & Pickled

    Stainless Steel Bright Annealed Welded Pipes Round ASTM A358 Standard
