    Cold Drawn Carbon Steel Heat Exchanger Tubes Outer Diameter 6 - 140mm

    Ask Lasest Price
    Brand Name : HDT
    Model Number : SAE1020 SAE1045
    Certification : SGS ISO MTC
    Price : 800 - 9000 USD / ton
    Payment Terms : T/T, L/C at sight
    Supply Ability : About 10000 ton / month
    Delivery Time : Within 60 days after getting the DP
    • Product Details
    • Company Profile

    Cold Drawn Carbon Steel Heat Exchanger Tubes Outer Diameter 6 - 140mm

    Cold Drawn Seamless Steel Tube Precision Tube Outer Diameter 6.35-140mm Inner Diamter 13-130mm


    ASTM A213 DIN 17175 Annealed Cold Drawn Seamless Steel Tube , Carbon Steel Liquid Pipe

    Quick Detail:

    1,Standards: ASTM / DIN / EN / GOST / SAE / JIS etc

    2,Material Grade: Carbon Steel / Alloy Steel or According to requirements.

    Size: (mm)

    OD: 6-140mm

    WT: 0.5-20mm;

    Length: max 25000mm

    Description:

    Product name: Heat Exchanger Tubes / Cold Drawn / ERW

    Standard executived: ASTM / DIN / EN / GOST / SAE / JIS etc

    (ASTM A179,ASTM A199, ASTM A200, ASTM A213, DIN 17175,JIS G3462,JIS G3458 )

    Outside diameter:12.7mm

    Wall Thickness:2.11mm

    Length:6m-25m,also can be manufactured according to customers' requirements

    Type:Cold Drawn or ERW

    Ends:Plain ends or bevel ends

    Delivery Conditions: BK,BKS,BKW,NBK,GBK( As drawn, quenched and tempered, normalized, annealed, stress-relieved)As different requirements,It including pickling,etc. AS per Standard.

    Coating for protection:black painting,anti-rust oiled or varnish,also can be required according to customers' requirements

    Factory test and other terms:

    1.Hydrostatic or Nondestructive Electric Test

    2.Heat Treatment: according to Standard
    3.Surface Condition:According to Standard.
    4.Grain Size:According to standard
    5.Sampling:flattening,flaring,grain size,Marking

    6.we provide bevel end,plastic cap, varnish coating, oiled or black painted to prevent rustand other packing

    service.

    Main Specification Details:

    NameCold drawn or ERW straight steel tubes and pipes for heat exchanger
    Standard

    Meet or exceed ASTM,ASME,API,ANSI and DIN standards.

    ASTM A106/A179/A192/A210/A213/A519 etc.

    DIN2391/DIN17175/EN10305 etc

    GB8162/GB8163/GB3639 etc

    Material

    A179,St35,St45,St52,E215,E235,E355,10,20,

    A106,A179,A192,A210,T11,T22,T12 etc

    Size

    Outer diameter:6-114.0mm

    Wall thickness:0.5-15mm

    Length:max 2400mm,generally 6000mm

    Application

    Cold drawn or cold rolled precision seamless steel tubes for hydraulic pressure and pneumatic services.


    For Auto use,machinery use,oil cylinder tube,motorcycle shock reducer use,auto shock reducer inner cylinder,etc.

    Seamless steel pipes for low and medium pressure boiler, high pressure boiler,

    ship-building,Liquid service, petroleum cracking, chemical fertilizer equipment,

    Drawing-oil-equipment and structure purposes.

    Business scope

    DIN series cold drawn precision seamless steel tubes

    DIN series cold rolled precision seamless steel tubes

    Related coated and galvanized steel tubes

    Rustproof phosphyorylated tube

    Main characteric

    No Oxidation Layer on the outer and inner walls;

    No Leakage under high pressure;

    No Crake under flating and flattening;

    No distortion after cold bending;

    High precision high cleanness;

    Excellent brightness

    cold drawn and hot finished

    Superior performance for high pressure and temperature uses

    Black finish and hot dip galvanized

    Excellent corrosion resistance

    Delivery condition:

    DesignationSymbolDescription
    Cold finished (hard)BKTubes do not undergo heat treatment following the final cold forming and, thus, have a rather high resistance to deformation.
    Cold finished (soft)BKWThe final heat treatment is followed by cold drawing involving limited deformation. Appropriate further processing allows a certain degree of cold forming. (e.g. bending, expanding).
    Cold finished and stress-relievedBKSHeat treatment is applied following the last cold forming process. Subject to appropriate processing conditions, the increase in the residual stresses involved enables both forming and machining to a certain degree.
    AnnealedGBKThe last cold forming process is followed by annealing in a controlled atmosphere.
    NormalizedNBKThe last cold forming process is followed by annealing above the upper transformation point in a controlled atmosphere.

    All other tubes applicable for boiler and heat exchanger tube we can produce ,

    Chinese StandardSteel Grade/ No.American StandardSteel Grade/ No.
    GB5310

    20G,15MoG,12CrMoG,

    12Cr2MoG,15CrMoG,

    12Cr1MoVG,

    ASTM A106GR. A,B,C
    GB994810,20,12CrMo,15CMoASTM A53GR.A,B
    GB308710,20ASTM A192
    ASTM A179
    ASTM A210A-1,C
    ASTM A333GR.1,GR3,GR6
    ASTM A334GR.1,GR3,GR6
    ASTM A209T1, Ta, Tb
    German standardSteel Grade/ No.Japanese standardSteel Grade/ No.
    DIN17175ST35.8, ST45.8JIS G3454STPG370,STPG410
    DIN1629ST37.0, ST44.0, ST52.0JIS G3461STB340, STB410, STB440
    British StandardSteel Grade/ No.European standardSteel Grade/ No.
    BS3059-Ⅰ320EN10216-1P195TR1/TR2,P235TR1/TR2,
    P265TR1/TR2
    BS3059-ⅡS1/S2; TC1/TC2360,440,EN10216-2
    TC1,TC2
    195GH,P235GH,
    P265GH,

    Applications:

    1,For evaporator, heat exchangers, condensers, heat transfer equipment and similar tubes.

    2,Widely used in the mechanical treatment field, petrochemical industry, transport and construction field

    3,Ordinary structural purposes and mechanic structural purposes, for example in construction field, fulcrum bearing etc;

    4,The transportation of fluids in the projects and big equipments, for example transport of water, oil, gas etc

    5,Can be used in low and medium pressure boiler for the transportation of fluids, for example steam tube, big smoke tube, small smoke tube, generating tube etc


    Cold Drawn Carbon Steel Heat Exchanger Tubes Outer Diameter 6 - 140mmCold Drawn Carbon Steel Heat Exchanger Tubes Outer Diameter 6 - 140mm
