    168mm Boiler ASTM A210 Carbon Steel Seamless Tube For Power Station

    Ask Lasest Price
    Brand Name : HDT
    Price : 800 - 9000 USD / ton
    Payment Terms : L/C, T/T, Western Union, , MoneyGram
    Supply Ability : About 10000 ton / month
    Delivery Time : Within 75days after getting the down payment
    • Product Details
    • Company Profile

    168mm Boiler ASTM A210 Carbon Steel Seamless Tube For Power Station

    Product Description

    Boiler Tube ASTM A210 Carbon Steel Seamless Tube For Power Station

    Quick Detail:
    Standard: ASTM A210/A210M (ASME SA210/SA210M)
    Seamless Medium-Carbon Steel Boiler and Superheater Tubes
    Size:(mm)
    Out Dimensions: 12.7mm-114.3mm
    Wall Thickness: 0.8mm-15mm
    Length: 5-25mm


    Applications:

    It is used for boiler and boiler flue tubes. Including safe end, vault and supporting tube and super heater min wall thickness seamless medium--carbon steel tube


    Chemical Requirements:

    STANDARDGRADECHEMICAL COMPOSITION
    CSiMnPSCrMoCuNiV
    ASTM A210A-1≤0.27≥0.10≤0.93≤0.035≤0.035
    C≤0.35≥0.100.291.06≤0.035≤0.035


    Mechanical Properties:

    GradeYield Strength (Mpa)Tensile Strength (Mpa)Elongation (%)
    A-1≥255≥41530
    C≥275≥48530


    Wall Thickness Tolerance


    ASME SA-210
    ODWTWT Tolerance
    <=38.1/+20%,-0%
    >38.1/+20%,-0%

    Description:

    ASTM A210 is the standard covers seamless medium-carbon steel boiler and superheater tubes.ASTM A210 also covers minimum-wall-thickness, tubing sizes, boiler flues including safe ends, arch and stay tubes. ASTM A210 provides tensile and hardness properties but only applicable to certain size limitations. Material manufacturing shall be killed. Tubes shall be made by seamless process, marked as either hot-finished or cold-finished. Surface condition shall be specifically stated in the order. Chemical composition shall conform to the requirements. Elemental composition other than listed here shall not be permitted. Tension test, flattening test, flaring test, hardness test, hydrostatic or nondestructive electric test shall be made on specimens. Superheater tubes shall be formed without defects and shall withstand expansion, beading, forging, welding, and bending.


    ASTM A210/A210M Seamless Medium-Carbon Steel Boiler Tubes
    Seamless Medium-Carbon Steel Boiler and Superheater Tubes

    Steel Grde:
    Grade A1; Grade C
    Packing:
    Beveled/black painting/ plastic caps/ in bundles/ steel strips/ wooden protection
    Inspection and Test:
    Chemical Composition Inspection, Mechanical Properties Test(Tensile Strength, Yield Strength,Elongation, Flaring, Flattening, Bending, Hardness, Impact Test),Surface and Dimension Test,Nodestructive Test, Hydrostatic Test.
    Surface treatment:
    Oil-dip, Varnish, Passivation, Phosphating, Shot Blasting
    Mark:
    As requested.


    Delivery Condition:
    Annealed, Normalized, Normalized and Tempered
