6000mm Carbon Steel ASME SA-192 60mm Seamless Boiler Tubes for Power Plant

6,000mm Carbon Steel ASME SA-192 60mm Seamless Boiler Tubes for Power Plant

Quick Detail:

Standards: ASTM A192 (ASME SA192)

Grade: A192 SA192

Size: (mm)

OD: 6mm to 200mm;

WT: 1mm to 50 mm;

Length: 1 m ~ 12m

Related Specification Details:

Name	SA192 cold drawn straight seamless steel tubes and pipes
Standard	Meet or exceed ASTM,ASME,API,ANSI and DIN standards. ASTM A106/A179/A192/A210/A213/A519 etc. DIN2391/DIN17175/EN10305 etc GB8162/GB8163/GB3639 etc
Material	A192,St35,St45,St52,E215,E235,E355,10,20, A106,A179,A210,T11,T22,T12 etc
Size	Outer diameter:6-200mm Wall thickness:1-50mm Length:max 12,000mm,generally 6000mm
Application	Cold drawn or cold rolled precision seamless steel tubes for hydraulic pressure and pneumatic services. For Auto use,machinery use,oil cylinder tube,motorcycle shock reducer use,auto shock reducer inner cylinder,etc. Seamless steel pipes for low and medium pressure boiler, high pressure boiler, ship-building, Liquid service, petroleum cracking, chemical fertilizer equipment,Drawing-oil-equipment and structure purposes.
Business scope	DIN series cold drawn precision seamless steel tubes DIN series cold rolled precision seamless steel tubes Related coated and galvanized steel tubes Rustproof phosphyorylated tube
Main characteric	No Oxidation Layer on the outer and inner walls; No Leakage under high pressure; No Crake under flating and flattening; No distortion after cold bending; High precision high cleanness; Excellent brightness cold drawn and hot finished Superior performance for high pressure and temperature uses Black finish and hot dip galvanized Excellent corrosion resistance

Grade and Chemical Composition (%):

STANDARD	GRADE	CHEMICAL COMPOSITION
STANDARD	GRADE	C	Si	Mn	P	S	Cr	Mo	Cu	Ni	V
ASTM A192	A192	≤0.06-0.18	/	0.27-0.63	≤0.035	≤0.035
ASME SA106	SA106B	0.170.25	≥0.1	0.701.00	≤0.030	≤0.030	≤0.035
ASTM A106	A	≤0.25	≤0.10	0.270.93	≤0.035	≤0.035	≤0.40	≤0.15	≤0.40	≤0.40	≤0.08
	B	≤0.30	≤0.10	0.291.06	≤0.035	≤0.035	≤0.40	≤0.15	≤0.40	≤0.40	≤0.08
	C	≤0.35	≤0.10	0.291.06	≤0.035	≤0.035	≤0.40	≤0.15	≤0.40	≤0.40	≤0.08
ASTM A53	A	0.25	/	0.95	0.05	0.045	0.40	0.15	0.40	0.40	0.08
ASTM A53	B	0.3	/	1.2	0.05	0.045	0.40	0.15	0.40	0.40	0.08

Mechanical Properties:

Mechanical properties

Material

Min Tensile strenght

N/mm2

Min. Yield strengh

N/mm2

Min Elongation

A192

325

180

Tolerance Control:

OD In(mm)	+	-	WT In(mm)	+	-
<1(25.4)	0.10	0.10	≤1.1/2(38.1)	20%	0
1∼1.1/2(25.4∼38.1)	0.15	0.15	>1.1/2(38.1)	22%	0
>1.1/2∼<2(38.1∼50.8)	0.20	0.20	/	/	/
2∼<2.1/2(50.8∼63.5)	0.25	0.25	/	/	/
2.1/2∼<3(63.5∼76.2)	0.30	0.30	/	/	/
3∼4(76.2∼101.6)	0.38	0.38	/	/	/

Description:

Product name:ASME SA192/SA192M seamless carbon steel pipe

Standard executived: ASME SA192 SA192M, ASTM DIN JIS or GB standard

Outside diameter:6mm~200mm

Wall Thickness:1mm~50mm

Length:1m-12m,also can be manufactured according to customers' requirements

Type:Seamless (cold drawn)

Ends:Plain ends or bevel ends

Delivery Conditions: BK,BKS,BKW,NBK,GBK( As drawn, quenched and tempered, normalized, annealed, stress-relieved)As different requirements,It including pickling,etc. AS per Standard.

Coating for protection:black painting,anti-rust oiled or varnish,also can be required according to customers' requirements

Factory test and other terms:

1. Hydrostatic or Nondestructive Electric Test

2. Heat Treatment: according to Standard
3. Surface Condition:According to Standard.
4. Grain Size:According to standard
5. Sampling:flattening,flaring,grain size,Marking

6. we provide bevel end,plastic cap, varnish coating, oiled or black painted to prevent rustand other packing

service.

Applications:

1, For evaporator, heat exchangers, condensers, heat transfer equipment and similar pipes.

2, Widely used in the mechanical treatment field, petrochemical industry, transport and construction field

3, Ordinary structural purposes and mechanic structural purposes, for example in construction field, fulcrum bearing etc;

4, The transportation of fluids in the projects and big equipments, for example transport of water, oil, gas etc

5, Can be used in low and medium pressure boiler for the transportation of fluids, for example steam tube, big smoke tube, small smoke tube, generating tube etc
