    ASTM A210 Condenser Seamless Boiler Steel Tube Low Pressure

    Ask Lasest Price
    Brand Name : HDT
    Price : 800 - 9000 USD / ton
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : About 10000 ton / month
    Delivery Time : 60-75days
    • Product Details
    • Company Profile

    ASTM A210 Condenser Seamless Boiler Steel Tube Low Pressure

    ASTM A210 seamless medium carbon steel boiler and superheater tubes

    ASTM A210 is the standard covers seamless medium-carbon steel boiler and superheater tubes. Seamless medium carbon steel pipe for boiler tube and boiler flue pipe, including a minimum wall thickness of the security side, the dome and the support tube and superheater tubes.

    ASTM A210 Condenser Seamless Boiler Steel Tube Low Pressure


    Mechanical Properties:

    GradeC(Max)MnSi(Min)P(Max)S(Max)
    A10.27Max.0.930.100.0350.035
    C0.350.29~1.060.100.0350.035

    Chemical composition:

    GradeTensile Strength(Mpa)Yield Strength(Mpa)Elongation (%)
    A1≥ 415≥ 255≥ 30
    C≥ 485≥ 275≥ 30

    Outside Diameter & Tolerance

    Hot rolledOutside Diameter, mmTolerance, mm
    OD≤101.6+0.4/-0.8
    101.6<OD≤127+0.4/-1.2
    Cold DrawnOutside Diameter, mmTolerance, mm
    OD<25.4±0.10
    25.4≤OD≤38.1±0.15
    38.1<OD<50.8±0.20
    50.8≤OD<63.5±0.25
    63.5≤OD<76.2±0.30
    76.2≤OD≤101.6±0.38
    101.6<OD≤127+0.38/-0.64

    Wall thickness & Tolerance

    Hot rolledOutside Diameter , mmTolerance, %
    OD≤101.6, WT≤2.4+40/-0
    OD≤101.6, 2.4<WT≤3.8+35/-0
    OD≤101.6, 3.8<WT≤4.6+33/-0
    OD≤101.6, WT>4.6+28/-0
    OD>101.6, 2.4<WT≤3.8+35/-0
    OD>101.6, 3.8<WT≤4.6+33/-0
    OD>101.6, WT>4.6+28/-0
    Cold DrawnOutside Diameter , mmTolerance, %
    OD≤38.1+20/-0
    OD>38.1+22/-0

    Application:

    • For high, middle, low pressure boiler and pressure purpose
