Carbon Steel Boiler Fin Tube For Superheater Seamless Spiral Finned Heat
Exchanger Tube
Product Description
The finned tube is a heat exchanger element made of steel tubes,
which is made by winding fins around the base tube to form a finned
tube. There is a wide range of materials for finned tubes,
including stainless steel, carbon steel, titanium-copper alloys,
and more. This results in its wear-resistant and
corrosion-resistant properties. It can use water, steam, and heat
transfer oil as the medium of the radiator, and the heat
dissipation through the medium can achieve the purpose of raising
the indoor temperature. The finned tubes we offer can be used in a
wide range of economizers, evaporators, superheaters and air
heaters, and are excellent materials for boiler components.
Specifications
| Base Tube Material | Stainless Steel, Carbon Steel, Alloy Steel, Copper Alloy,Aluminum
,SA179 |
| Fin Material | Aluminum, Copper Alloy, Stainless Steel, Carbon Steel |
| Standard | ASME SA213/ASTM; ASME EA 106, ASME SA178, ASTM B1111 |
| Fin depth | 0.5-3mm |
| Base pipe O.D | 12.7-18mm |
| Fins per inch | 8-20Nos (as customer's request) |
| Test Requirement | Physical Property Test, Chemical Composition Analysis,
Non-Destructive Test, Other Inspection and Test as customer's
requirement. |
| Application | Air Cooler, Charge Air Chiller, Condenser, Evaporator, Fluid
Cooler, Gas Cooler, Oil Cooler, Radiator, Refrigeration, Steam to
Air Heat Exchange, super heater etc. |
Features
- Boiler Fin Tube: Round, Square, Rectangle, Oval, Finned, Etc.
- Surface Treatment: Pickling, Sand Blasting, Galvanizing, Etc.
- Fin Pitch: Customized
- Package: Wooden Cases, Pallet, Etc.
- Application: Boiler, Heat Exchanger, Condenser, Etc.
- Heat Exchanger Fin Tube: Carbon Steel Fin Tube, Stainless Steel Fin
Tube.
Advantages
1.The effective space increases the heat exchange area, improving
the heat transfer effect.
2. Reduce the occupied space of the heat transfer surface and
reduce its volume, especially suitable for quick-installation
boilers.
3. Reduce the cost of equipment and improve the safety of
equipment.
4. Lower operating costs due to the reduction of pressure drop on
the water side.
5. The stiffness of the finned tube is increased, improving the
seismic resistance of the tube.
Packing and Shipping
The boiler fin tubes are packaged in wooden crates or cartons, with
each tube wrapped with an individual cardboard sleeve. The crates
are then placed on a pallet and covered with a waterproof tarp to
ensure the safety of the tubes during shipping.
The shipping method will depend on the size and quantity of the
order. For smaller orders, the boiler fin tubes are shipped via
small package carriers such as UPS or FedEx. For larger orders, the
tubes are shipped via freight carriers such as R&L Carriers or
Estes Express.
About us
Zhangjiagang Hua Dong Energy Technology Co., Ltd. is a high-tech
enterprise specialized in producing all kinds of stainless, carbon
and alloy steel tubes and pipes, steel plates which are widely used
in the field of boiler&heat exchanger, energy, petrochemical,
mining, food, paper, gas and fluid industry. And we have passed the
attestations including ASME, TUV, Grade A, ISO9001, EN12952,
EN10216, SO3834.
The company is the subsidiary of Zhangjiagang Hua Dong Boiler Co.,
Ltd, which is the most leading boiler and boiler parts manufacturer
in China with a history of 35 years and annual turnover of 110
million U.S.A. dollars. Our products have been exported to over 30
countries like United States, Australia, Vietnam, Pakistan,
Albania, Cambodia, India, Indonesia, South Korea, the Philippines,
Turkey, Saudi Arab, Germany, Russia, Chile, Syria, Thailand,
Bangladesh, France, Algeria, Mongolia and Singapore, Cuba, Iraq,
Italy, Spain, Japan, Yugoslavia, Sri Lanka, the Czech republic,
kyrgyzstan, Canada, Malaysia, the United Kingdom and so on.
FAQ
Q: What is Boiler Fin Tube?
A: Boiler Fin Tube is a kind of heat exchanger that is widely used
in industrial boilers, HVAC systems, and other heat transfer
equipment.
Q: What brand is HD Boiler Fin Tube?
A: HD Boiler is a Brand Name of Boiler Fin Tube.
Q: Where is HD Boiler Fin Tube made?
A: HD Boiler Fin Tube is made in China.
Q: What certifications does HD Boiler Fin Tube have?
A: HD Boiler Fin Tube has ASME, ISO9001:2015, ISOEN3834
certifications.
Q: What is the minimum order quantity of HD Boiler Fin Tube?
A: The minimum order quantity of HD Boiler Fin Tube is 3 TONS.
